ULTRA – The Jeep of the skies
The ULTRA (Uncrewed Low-cost TRAnsport) platform was developed by Windracers in response to the need for a new type of cargo drone.
Our vision was to develop a robust and cost-effective drone, capable of addressing the challenging logistics problems associated with delivering essential logistics efficiently, to people who needed them in a timely fashion.
ULTRA is capable of carrying a payload of 100 kg up to 1000 km and is designed in line with our Zero Single Point of Failure philosophy to rigorously eliminate all risk including avionics, communications and ground control.
Innovative autonomous technology
Windracers’ drones are uncrewed and fly autonomously, controlled by our advanced autopilot solution Masterless™. Masterless™ is an entirely new architecture that has been developed and patented by our sister company Distributed Avionics, providing best in class autopilot technology for drones in the world.
Distributed Avionics was founded by Windracers to design and build an affordable and extremely robust autopilot solution that adheres to our rigorous design philosophy.
ULTRA: At a glance
|1||Distance||Up to 1,000 km|
|2||Payload||Up to 100 kg|
|3||Internal payload||700 L volume|
|4||Take off and landing||150 m in any direction|
|5||Structural materials||95% aluminum|
|6||Control surfaces||24 interchangeable control surfaces|
|7||Engine||2 twin stroke engines|
|8||CO2 output||30% of CO2 output per kilo of payload
(in comparison to twin prop light aircraft)
|9||Empty weight||300 kg|
|10||Maximum take-off weight||450 kg|
|11||Cruise speed||135 km/h|
|12||Take-off and landing||200 m (no wind)|
|13||Nominal endurance||12+ hours|
|14||Electrical power||350 W|
|15||Runway||Dirt, grass, tarmac and ice|
